Redmond Gary – 40kN – Recovery Winch with HINO 300 SERIES TRUCK

Redmond Gary – 40kN – Recovery Winch with HINO 300 SERIES TRUCK | RW40KN-02

Overview:
The Recovery winch, equipped with a hydraulic motor and epicyclic reduction gearbox, delivers an average line pull of 40kN (4 Tonne). Its innovative "high-low" system adjusts speed dynamically offering high speed at low pull and switching to high pull at a reduced speed upon surpassing a preset load threshold. Direction is managed via a manual three-position directional valve, with a neutral setting that stops the winch by rerouting flow back to the tank, ensuring precise control and versatility for various recovery scenarios.



Features:

  • Recovery Winch
  • Power Pack - Hydraulic System
  • Control Panel



Mine spec body features

  • SAFETY STEPS
  • FULLY WELDED CONSTRUCTION
  • REINFORCED DROP SIDES
  • 3MM CHECKER PLATE FLOOR
  • LIGHT PROTECTOR PANELS
  • ALUMINIUM CHECKER PLATE GUARDS
  • FULL LENGTH PIPE TIE RAILS
  • WELDED TRAY MOUNTS
  • FULLY SAND BLASTED, ZINC PRIMED AND POWDER COATED





Specifications:

  • Average Line Pull (full drum): 40 kN
  • Maximum Line Pull (empty drum): 80 kN
  • High Speed (full drum): 24 m/min
  • Low Speed (full drum): 12 m/min
  • Winch Drum Capacity: 750 m for 16 mm diameter synthetic fibre rope (not included)



RW40KN-02
